TECTYL® 603
POLYMERIC, WATER EMULSIFIABLE CORROSION PREVENTIVE
Tectyl 603 General Information:
TECTYL 603 is a polymeric, water emulsifiable corrosion preventive. It is specially formulated for coating phosphated and painted parts such as hinges, bolts, screws, brackets, fasteners, etc. It contains a special additive system which provides a durable, self-healing, corrosion resistant film. The concentrated coating is an amber liquid. The cured film is clear and transparent.
Benefits
Easy Application TECTYL 603 is applied as a water emulsion. It is normally applied in a dipping operation. Long-Term Protection TECTYL 603 deposits a self-healing film on phosphated parts and components that provides salt spray protection superior to conventional water soluble rust preventive oils.
Phosphated parts coated with an emulsion of 20 percent TECTYL 603 and 80 percent water will pass the 240 hour salt spray test requirement of the General Motors 6035-M phosphating specification.
The maximum protection of TECTYL 603 can only be obtained when applied to properly phosphated components.
TECTYL 603 will not compensate for inadequate phosphating. Adequate phosphating per the General Motors 6035-M specification is 2,000 - 3,000 milligrams of zinc phosphate per square foot of coating area.
TECTYL 603 Application:
1. Charge tank with de-ionized water.
2. Begin mixing and bring water temperature to 140 - 160F (60 - 71C).
3. Add TECTYL 603 slowly, with agitation, to develop a 20 percent emulsion. WHEN MIXING, ALWAYS ADD TECTYL 603 TO THE WATER, NEVER IN REVERSE ORDER.
4. The TECTYL 603 emulsion temperature at the time of initial fill and application should be 140 - 160F (60 - 71C).
5. Mechanical agitation (not air) is required at all times
System Maintenance
A properly maintained system is important for optimum performance. To ensure proper protection, the pH and emulsion concentration of TECTYL 603 should be checked at least once daily. Refer to Technical Bulletin #29 for complete information regarding maintenance and handling procedures.
TECTYL 603 Storage:
Store Tectyl 518 at temperatures between 50-95°F (10-35°C). Mild agitation is recommended prior to use.
TECTYL 603 Caution:
Refer to Daubert’s Material Safety Data Sheet for additional handling and first aid information.
TECTYL 603 Note:
The addition of any product over or under this coating is not recommended. The use of additional coatings could result in chemical incompatibility, thus adversely affecting the performance of this coating as stated in the lab data section. If a product other than Daubert Chemical Company's recommended product is required, written authorization must be obtained from Daubert Chemical Company.
Recommendations set forth in this product information sheet are based on testing, research and other development work which has been carefully conducted by Daubert Chemical Company, and they believe such data, statements and recommendations will serve as reliable guidelines. However, this product is subject to numerable uses under varying conditions over which they have no control, and accordingly, we do NOT warrant that this product is suitable for any particular use. Users are advised to test the product in advance to make certain it is suitable for their particular production conditions and particular use or uses.
Recommendations set forth in this product information sheet are based on testing, research and other development work which has been carefully conducted by Daubert Chemical Company, and they believe such data, statements and recommendations will serve as reliable guidelines. However, this product is subject to numerable uses under varying conditions over which they have no control, and accordingly, we do NOT warrant that this product is suitable for any particular use. Users are advised to test the product in advance to make certain it is suitable for their particular production conditions and particular use or uses.
TECTYL 603 Warranty:
Daubert Chemical Company, Inc. (“Daubert©?) warrants all products manufactured by it to be free from defects in material and workmanship. DAUBERT MAKES NO OTHER WARRANTIES, WHETHER, EXPRESSED OR IMPLIED, WITH RESPECT TO SUCH PRODUCTS, AND ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND IMPLIED WARRANTIES ARISING FROM A COURSE OF DEALING OR USAGE OF TRADE, ARE DISCLAIMED BY DAUBERT.
All claims hereunder must be made in writing within 30 days after receipt of the products at the buyer’s plant and prior to further processing the products or combining them with other materials or products. Daubert’s liability, whether under this warranty or in contract, tort, negligence or otherwise, is limited to the return of the net purchase price paid for any products proven defective or, at Daubert’s option, to the repair or replacement of said products upon their return, transportation prepaid, to Daubert. THE REMEDY HEREBY PROVIDED SHALL BE THE EXCLUSIVE AND SOLE REMEDY OF THE BUYER, AND UNDER NO CIRCUMSTANCES SHALL DAUBERT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES.
Daubert representative or other person is authorized to change this warranty in any way or to assume for Daubert any other liability in connection with the sale or use of its products. REFER TO Material Safety Data Sheet FOR HEALTH AND SAFETY INFORMATION.
